CBS-031 - CBS-061
AUTOMATIC BATTERY CHARGERS FOR LEAD BATTERIES
In conformity to DIN 41773 Standard
3A or 6A automatic battery chargers for installation inside electric switchboard, which can be connected to control units C-12845-485 or C-12845/1200. KEY FEATURES
| - Automatic charge in three levels (RAPID with current control, INTERMEDIATE or MANTENANCE with voltage control). |
| - Warning alert for short cicuit, polarity inversion, battery cables disconnection. |
| - Serial output RS-485. |
| - Output for remote indicator lights. |
| - Mounting hook for DIN rail in front (standard) or at the side. |
| - Energy saving. |
IDENTIFICATION DATA
| Type | Code | |
| CBS-031 12V | 3,5 A | 00010440 |
| CBS-061 12V | 6 A | 00010444 |
| CBS-061 24V | 6 A | 00010445 |
